Quick Details

  • Place of Origin: Fujian, China (Mainland)
  • Brand Name: TID
  • Model Number: TD-V30
  • Type: Handheld
  • Dimensions: 107*54*31mm
  • Frequency Range: 136-174MHz/400-470MHz
  • Storage Channel: 16
  • Talk Range: 5km
  • Color: Black
  • Operation Voltage: 7.4V
  • CTCSS/DCS: Yes
  • Emergency Alarm: Yes
  • Battery Capacity: 1500mAh(Li-ion)
  • Operating temperature: -20 to 60℃
  • Power output: LO:1W HI:5W
  • TOT: Yes
  • weight: 210g
  • Battery Life: about 12hours

Packaging & Delivery

Packaging Details Gift box packing

        TID Td-v30 walkie talkie CE single band portable hand-held radios 136-174/ 400-470mhz





Product Description





  • Voice Annunciaion :16 channels by voice annunciation
  • Battery capacity: 1500mAh Li-ion battery for long time operation
  • Loud speaker:40mm loud speaker fr cear audio output
  • Power switchable function :high / low power switchable
  • Time out timer(TOT)
  • Auto batter save













Main Features for TD-V30 radio talkie walkie



  • Modern Fashion compact design
  • 16 channels by voice annunciation
  • 51 groups of CTCSS Encode & Decode
  • 214 CDCSS Encode & Decode
  • 1500mAh Li-ion Battery fo long time operation
  • 40mm loud speaker for clear audio output
  • smart MCU control charger
  • 9 squelch level
  • channel scan
  • high / low power switchable
  • programmable 25kHz / 12.5kHz channel spacing
  • monitor
  • time out timer
  • auto battery save
  • emergency alert

1). Specification of High cost-effective profesional 2 way radios( TD-V30)

1). Frequency Range

VHF:136-174MHz ,UHF:400-470MHz

2). Channel Capacity16
3). Channel Spacing12.5 / 25.0KHz
4). Operation VoltageDC7.4V
5). Battery Capacity1500mAh(Li-Ion)
6). Battery Life(5-5-90 Duty Cycle)About 15Hours
7). Frequency Stability± 2.5ppm
8). Operating Temperature-20~ 60 °c
9). Antenna Impedance50 Ω
10). Dimension(H*W*D)(Without Antenna)107*54*31mm
11). Weight(With Antenna & Battery)220g



2).Accessories

1).Battery Pack1 set
2.Antenna1 set
3).Charger1 set
4).AC Adapter1 set
5).Belt Clip1 set
6).Hand strap1 set



3).Transmitter

1). RF power outputUHF:5.0W /1.0W ,VHF:5.0W / 1.0W
2). Modulation typeF3E
3). Spurious and harmonics-36dBM < 1GHz; -30dBm >1GHz
4). FM Noise40 /45dB
5). Audio Distortion≤5%
6). Audio Response1 to -3dB



4).Receiver

1). Sensitivity≤ 0.30 / 0.20V
2). Adjacent channel selectivity60dB
3). Intermodulation65dB
4). Spurious Response Rejection65dB
5. S/N40 / 45dB
6). Audio Power output600mW
7). Audio Distortion≤ 5%
